Specialty Water Management
AMCO offers two specialty water management tools.
![AMCO-Pivot-Tile-Plow-Cutout-WEB Pivot/Tile Plow: PTP](https://www.amcomfg.com/wp-content/uploads/2023/06/AMCO-Pivot-Tile-Plow-Cutout-WEB.jpg)
Border Plow: BP
Border Plow
Model | Cutting Width | No. of Discs | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs.* |
---|---|---|---|---|---|
BP-624 | 5 1/2′ | 6 | 4 | 50 and up | 700 |
*To calculate weight/blade, divide the approximate weight of the model by the number of disc blades.
Specifications subject to change without notice.
![Full view of Border Plow on dirt and grass](https://www.amcomfg.com/wp-content/uploads/2014/05/border-plow-folded.jpg)
The Border Plow (BP) is the perfect water management solution to build borders and levees around fields. Angled-down gangs on 2′ spacing create the perfect barrier to keep water in or out and manage erosion.
The Border Plow blade setup consists of one 24″ x ¼” (6mm) cutout blade on the inside and two 24″ x ¼” blades on the outside. Blade spacing is 9″.
Other BP features:
- Features 1½” square, high-carbon, cold-rolled steel axles
- Features Protect-O-Shield® Bearings: greaseable, 1½” square-bore, ball-type, toggle-mounted with zerk and wear guards
- Transport width: 7′
- 3-point hitch fits category I, II, and III hitches (quick-hitch compatible)
- Features straight standard cast gang risers
- Main frame tubing: 4″ x 7″ x ⅜” x 80″ rectangular
Pivot / Tile Plow: PTP
Pivot / Tile Plow
Model | Cutting Width | No. of Discs | No. of Bearings | Approx. Engine HP Required | Approx. Weight lbs.* |
---|---|---|---|---|---|
PTP-624 | 5 1/2′ | 6 | 4 | 50 and up | 700 |
*To calculate weight/blade, divide the approximate weight of the model by the number of disc blades.
Specifications subject to change without notice.
![Side view of Pivot/Tile Plow](https://www.amcomfg.com/wp-content/uploads/2014/05/tile-pivot-plow-3.jpg)
AMCO’s Pivot/Tile Plow (PTP) is ideal for fixing pivot ruts and soil ridges left after tile installation. If soil leveling is your goal, our Pivot / Tile Plow is the tool for the job.
The PTP blade setup consists of one 24″ x ¼” (6mm) cutout blade on the inside and two 24″ x ¼” blades on the outside. Blade spacing is 9″.
Other PTP features:
- Features 1½” square, high-carbon, cold-rolled steel axles
- Features Protect-O- Shield® Bearings: greaseable, 1½” square-bore, ball-type, toggle-mounted with zerk and wear guards
- Transport width: 7′
- 3-point hitch fits category I, II, and III hitches (quick-hitch compatible)
- Features angled standard cast gang risers
- Main frame tubing: 4″ x 7″ x ⅜” x 80″ rectangular
